The sensor level bar graph provides the following real-time information:
■ The sensor level bar graph provides a graphic display of the sen-
sor’s output value. The scaling of the bar graph changes to match
the output of the specific sensor.
■ The digital display in the lower left shows the current sensor out-
put value in the appropriate engineering units.
■ The digital display in the lower right shows the sensor’s output as
a percent of full scale.
Communication Module Point Display
S
ENSOR
L
EVEL
B
AR
G
RAPH
3.7
