5.1

95-8599

STRAPD

String Append. When the enable input is True, source string 2 is

appended to the end of source string 1 and placed in the destination

string.

No

STRCPY

String copy. When the enable input is True, the source string is copied

to the destination string.

No

STNCPY

String “n” copy. This function is used to extract parts from a string.

When the enable is True, not more then ‘Count’ characters starting with

character ‘Index’ are copied to the destination string.

No

STREQ

String Equal. When the enable input is True, source string (S1) is

compared to source string (S2).

No

SUB

Subtract. The input values can be integer, double or float. The output

will be the same type as the input.

Yes for all but

floating-point

TDSTR

Time and Date to String. When the enable input is True, the time/date

value is converted to a string. The input value can come from any valid

time/date source. The output format is selectable.

No

TOF

Off Timer. TOF provides a delay of time from the falling edge of the

input.

No

TOF-SIL

The SIL version of the Off Timer is the same as the normal TOF function,

with the addition of duplicate storage for elapsed time variable.

Yes

TON

On Timer. TON provides a delay of time from the rising edge of the

input

No

TON-SIL

The SIL version of the On Timer is the same as the normal TON

function, with the addition of duplicate storage for elapsed time variable.

Yes

TRUNC

Truncate. The Input value is a float. The result will be a double; e.g.

123.456 = 123

No

UNPK16

Unpack. The input value Is an integer. This function performs a bitwise

unpacking of the input into Booleans.

Yes

UPKDT

Unpack Date/Time. This function performs an unpacking of a Date/

Time to 6 integers.

No

XOR

Exclusive OR. The input values are Booleans. The output is True when

the number of True inputs is odd.

Yes

XORW

XOR WORD. The input values can be integer or double. All values

must be of the same type, and the result will be of the same type. This

function performs a logical XOR of the inputs.

Yes

25
