5.1

95-8599

PKDT

Pack Date/Time. This function performs packing of 6 integers into a

Time/Date data type.

No

PULSER

Pulser. This function block creates periodic pulse of defined ON and

OFF time-values. The ON and OFF time-values may be different.

RND

Round. Half way values are rounded to the nearest even number

(Bankers rounding). The input value is a float. The result will be a

double; e.g. 5.5 rounds to 6, 6.5 rounds to 6, -5.5 rounds to -6, -6.5

rounds to -6.

No

RS

Reset/Set. If Reset input is set to True, then the output is False. If Set

input is set to True and Reset input is False, then the output is True. If

both are False, then there is no change in the output. This gate is Reset

dominant bistable. If the Reset input is True, then the output is False,

regardless of the Set input.

No

RS-SIL

SIL Reset/Set gate. The SIL Reset/Set gate operates the same as the

standard RS, but provides duplicate storage for the persistent value.

Yes

RTM

Retentive Timer. This function block performs a Retentive On Timer

function. It provides a delay of time PT from the rising edge of input IN.

No

RTM-SIL

SIL Retentive Timer. The SIL Retentive Timer operates the same as

the standard Retentive Timer, but provides duplicate storage for the

persistent values.

Yes

SCALE

Scale. The input values can be integer, double or float. All the values

must be of the same type. The output will be of the same type. The first

value is the input. The second value is the low range for the input. The

third value is the high range for the input. The fourth value is the low

range for the output and the fifth value is the high range for the output.

No

SEL

Selector. The True and False input values can be Boolean, integer,

double, string or float. They must be of the same type and the output

will be of this type. The selector input value is a Boolean. If the selector

is False, then the value at the False connection is passed to the output.

If the selector is True, then the value at the True connection is passed to

the output.

Yes for all but

floating-point

and string

values

SQR

Square. The input value is a float. The result will be a float.

No

SQRT

Square Root. The input value is a float. The result will be a float.

No

SR

Set/Reset. This function block performs a Set-Reset function. If the

Set input is set to True, then the output is True. If the Reset input is set

to True and Set input is False, then the output is False. This gate is the

Set dominant bistable. If the Set input is True, then the output is True,

regardless of the Reset input.

No

SR-SIL

SIL Set/Reset. The SIL Set/Reset gate operates the same as the

standard Set/Reset gate, but provides duplicate storage for the

persistent value.

Yes

24
