5.1

95-8599

MOFN

M of N. All of the Boolean inputs are examined for a True condition. The

result is compared against the Preset (PR). The output “>” is True if the

count is greater than the PR. The output “=” is True if the count is equal

to the PR. The output “<” is True if the count is less than the PR.

Yes

MOSP

Multiple One Shot Pulse. The inputs are Boolean. The output is a

Boolean. Each input has a one-shot pulse function. The output is the

“OR” of all of the inputs after the result of each one-shot pulse function.

No

MUL

Multiply. The input values can be integer, double or float. The inputs

must be of the same type. The result type is the same as the inputs.

Yes for all but

floating-point

values

MUX

Multiplex. The input values can be Boolean, integer, double, string or

float. All input values must be the same type. The output is the item

indexed by the selector input. The output will be the same type as the

inputs.

Yes for all but

floating-point

and string

values

NBITS

Number of Bits. The output will be the sum of all the binary inputs.

Yes

NE

Not Equal To. The values can be integer, double or float. The result is a

Boolean.

Yes for all but

floating-point

values

NOT

NOT. The input values can be Boolean, integer or double. The output is

the bitwise NOT of the input.

Yes

ODD

ODD. The input values can be integer or double. The function

determines if the input value is odd. The result is a Boolean.

Yes

OR

OR. OR reads all the Boolean values, performs a bitwise OR function

and writes the result. The result is a Boolean.

Yes

ORW

OR WORD. The input values can be integer or double. All values must

be of the same type and the result will be of the same type. This

function performs a logical OR of the inputs.

Yes

OSP

One shot pulse. The input is a Boolean. The output is a Boolean.

When the input goes True, the output goes True for one program scan.

The output will be False the next time the function block is executed,

regardless of the input.

No

OSP-SIL

One shot pulse SIL. The input is a Boolean. The output is a Boolean.

When the input goes True, the output goes True for one program scan.

The output will be False the next time the function block is executed,

regardless of the input.

Yes

OUTPUT

Output. The output can be any value. The output function is used to

select an output that will be directed from logic.

Yes for all but

floating-point

and string

values

PACK16

Bit Packing. This function performs a bitwise packing of the Boolean

inputs into an integer.

Yes

23
