5.1

95-8599

BTWT

Between Time Compare. There are three input time/date items. Two are

the comparison values and the third is the compare item. If the compare

item is equal to or between the comparison values, a Boolean True is

output, if not a Boolean False is output; e.g. if the <= input is 15:00:00

and the IN input is 12:00:00 and the >= input is 06:00:00 then the

output would be True.

No

CEIL

Ceiling. This function performs a round up. The input is a float. The

result will be a double; e.g. –2.8 = -2, 2.8 = 3, -1 = -1

No

CTD

Down Counter. There are three inputs. They are “count down (CD)”

a Boolean, the “Load (LD)” a Boolean, and the “Preset Value (PV)” a

double.

When the LD input is False, the counter counts down. One count for

each CD transition from False to True.

The output is True if the current value is less than or equal to zero. The

counter stops counting when the current value reaches -2,147,483,648.

When the LD is True, the PV is loaded into the current value to initialize

the counter.

No

CTD-SIL

SIL Down Counter. The SIL Down Counter operates the same as the

standard CTD, but provides additional error checking in the Controller

against random memory error.

Yes

CTU

Up Counter. There are three inputs. The “count up (CU)” a Boolean, the

“Reset (R)” a Boolean, and the “Preset Value (PV)” a double.

When the R input is False, the counter counts up. One count for each

CU transition from False to True.

The output is True if the current value is greater than or equal to

the PV. The counter stops counting when the current value reaches

2,147,483,647. When R is True the current value is set to 0.

No

CTU-SIL

SIL Up Counter. The SIL Up Counter operates the same as the standard

CTU, but has additional error checking in the Controller against random

memory error.

Yes

CTUD

Up/Down Counter. This has five inputs. The “count up (CU)” a Boolean,

the “count Down (CD)” a Boolean, the “Reset (R)” a Boolean, the “Load

(LD)” a Boolean and the “Preset Value(PV)” a double.

When the LD and R inputs both are False, the counter counts.

One count up for each CU transition from False to True.

One count down for each CD transition from False to True.

If both CU & CD transition, the counter will count up.

If the current value is greater than or equal to the PV, QU output is True.

If the current value is less than or equal to zero, QD output is True.

The counter stops counting when the current value reaches

2,147,483,647 or -2,147,483,648.

When the R is True the current value is set to zero.

When the LD is True the PV is loaded into the current value to initialize

the counter.

No

20
