5.1

95-8599

17

Certified for use up to

SIL 2

Configuration

1oo1D

Architecture Type

B

Hardware Fault Tolerance

0

Safe Failure Fraction

> 90%

Failure Rate Data

Part

Model

l

DU

(dangerous undetected failure rate per 10

9

hours)

Sff %

EQP Safety Controller

EQ3xxx

87.5

96.7

EDIO Safety Module -

Configured as Input*

EQ3730EDIO

Common = 20.9

Input Monitored for Opens = 6.6

Input Monitored for Opens & Shorts = 0.68

97.1

93.0
99.0

EDIO Safety Module -

Configured as Output*

EQ3730EDIO

Common = 20.9

Output Monitored for Opens, Opens & Shorts = 0.92

97.1

98.9

AIM Safety Module

EQ3710AIM

Common = 12

Per Input Channel = 5.16

98.1
93.0

X3301 IR Flame Detector

X3301

133

96.3

Eclipse IR Gas Detector

Model PIRECL

132

95.5

EQP Safety Communications

22.8

n/A

* “Common” are components common to both inputs and outputs. For lDU calculation:

Example 1: Input and output on same EDIO

l

DU = Common + Input + Output

l

DU = 20.9 + 0.68 + 0.92 = 22.5

Example 2: Input and output on different EDIOs

l

DU =

l

DU EDIO #1 +

l

DU EDIO #2

= (Common + Input) + (Common + Output)

= (20.9 + 0.68) + (20.9 + 0.92) = 43.4

Product Life EQ3xxx (Controller): 10-25 years, based on manufacturer data.

Product Life EQ3730EDIO: 6-29 years, based on manufacturer data.

Product Life EQ3710AIM: 6-29 years, based on manufacturer data.

Product Life X3301: 12-27 years, based on manufacturer data.

Product Life PIRECL: 5-40 years, based on manufacturer data.

All failure rate data for SIL verification is in the FMEDA report, which is available upon request.

IEC 61508 failure Rates
