5

95-8556

10.1

faUlT INDICaTION
Faults and status conditions are indicated using the 4-20

mA analog signal output. Refer to Table 3. Signaling

modes include two predefined and one user defined

mode. OPGD-Rx mode (default) is available as well as

a user defined mode for third party compatibility.

TRaNSmITTER lamp OpERaTION
Dual xenon lamps illuminate the linear detection path

from the transmitter to the receiver. Should excessive

degradation of the light intensity occur, the transmitter

automatically increases the light output of the bulbs.

The receiver recognizes this condition by the change

in flash pulse coding and responds by initiating a "Tx

Lamp Fault" warning signal. Total system operation

is maintained, with no loss of sensitivity or detection

performance.

In this mode of operation, the following occur:

1. The indicator LED turns yellow on both the

transmitter and the receiver.

2. HART and MODBUS communication warn of a “Tx

Lamp Fault” condition.

3. The 4-20 mA signal drops from a normal 4 mA to 3.0

mA in OPGD-Rx mode (default) or 2.4 mA in PIR9400

mode. The analog output value is overridden if the

gas level exceeds 0.5 LFL-meters. All gas alarm

signals will occur as normal.

4. The EQP system indicates a trouble condition.

Service should be arranged as soon as possible. A new

transmitter module should be installed.

noTe

The “Tx Lamp Fault” condition indicated by the
4‑20 mA output can be acknowledged by applying
a magnet to the transmitter module for at least
5 seconds. The coded flash sequence will then
return to normal, which causes the 4‑20 mA signal
at the receiver module to also return to normal.
The indicator LeD on the receiver will return to
green, however, the indicator LeD on the transmitter
will remain yellow to annunciate the lamp fault
condition. This condition will continue until power
to the transmitter unit is cycled or the lamps no
longer operate.

Table 3—Detector Status Conditions Indicated by Current Level

*Device is still functional. Gas overrides this indication.

Status

4-20 ma level (±0.1)

OpgD-Rx pIR9400

(Default)

Normal Gas: –0.35 to 5 LFL-M 2.88 to 20.0 2.88 to 20.0
Warmup

1.0 1.0

Zero Calibration

1.0

2.2

Calibration Fault

1.0

1.6

Beam Block

2.0

1.0

Tx Lamp Fault*

3.0

2.4

Calibrate Active at Startup

1.0

0.6

EE Error

1.0

1.2

Ref. ADC Saturated

1.0

0.2

Active ADC Saturated

1.0

0.4

24 VDC Fault

1.0

0.8

Zero Drift

1.0

2.4

Flash CRC Error

1.0

1.2

RAM Error

1.0

1.2

Over Range

20.4

20.4
