Det-Tronics OPECL Infrared Hydrocarbon Gas Detector - Manual (Page 40)

10.1 95-8556 F-2
open pATH eClipse HART menu sTRuCTuRe
This section displays the menu trees for the Open Path Eclipse. The Menu tree shows the primary commands
and options available when using menu selections.
OPGD RX Root Menu
1) Process Menu
2) Status Menu
3) Setup Menu
4) Calibration Menu
5) Test Menu
Process Menu
1) Gas Name
2) PV. Digital Value
3) PV. Analog Value
4) PV. Upper Range Value
General Info Menu
1) Mfg.
2) Device Type (Model)
3) Final Assy Number
4) Device ID
5) Tag
6) Date
7) Descriptor
8) Message
RTC Menu
1) Seconds
2) Minutes
3) Hours
4) Date
5) Month
6) Day
7) Year
8) Write Protect
Alignment Status Menu
1) Quad X*
2) Quad Y*
3) Reference
Coefficient Menu
1) Coefficient A
2) Coefficient B
3) Coefficient C
4) Coefficient D
5) Coefficient E
Fault Status Menu
1) Current Op Mode 1
2) Current Op Mode 2
2) Fault 1
3) Fault 2
4) Status 1
5) Status 2
Alignment Menu
1) Quad X*
2) Quad Y*
3) Reference
4) Enable Alignment
5) Disable Alignment
Debug Menu
1) Blocked Optics Cnt
2) Rcv Flash IRQ Cnt
3) Ext Cnt IRQ Cnt
4) Current SS Cnt
5) Current GP Cnt
6) LoopBack Err Cnt
7) Low 24v
8) 24v ADC
9) Flash Cnt
10) Flash Cnt x 10K
11) Quad Threshold*
12) Gas Threshold
13) Fix Quad Gain*
14) Fix Gas Gain**
Diag / Test Menu
1) Self Test
2) Response Test
3) Reset
4) Loop Test
5) Debug Menu
6) Alignment Menu
Calibration Menu
1) Gas Type
2) Cal Date
3) User Span Cal Delta
4) Zero Calibration Method
Alarm Menu
1) High Alarm Level
2) High Alarm Latch
3) Low Alarm Level
4) Low Alarm Latch
RTC Menu
1) RTC Menu
Setup Menu
1) OPGD Option Menu
2) Hart Output Menu
3) Com - 485 Menu
4) Config Flt Output Menu
5) Gas Type Menu
6) Range Menu
7) Alarm Menu
8) D/A Trim Method
9) RTC Menu
Write Protect Menu
1) Password
2) Set Write Protect
3) Write Protect Bit
Hart Output Menu
1) Write Protect Menu
2) Poll Address
3) # Required Preams
4) Tag
5) Date
6) Descriptor
7) Message
OPGD Option Menu
1) PV.Digital Units
2) Blocked Optics Timer
3) Heater Control
4) Distance
5) AZT Level*
6) AZT Zero Drift Limit*
7) AZT Con Suppress*
8) Assembly Number
Protocol Menu
1) Modbus
2) ASCII
Config Fault Output Menu
1) Analog Fault Codes
2) Analog Code Values
Baud Rate Menu
1) 1200
2) 2400
3) 4800
4) 9600
5) 19.2K
Analog Fault Code Menu
1) OPGD-Rx
2) PIR-9400
3) User Defined
Range
Menu
1)URV
2)LRV
3)USL
4)LSL
Parity Menu
1) None
2) Even
3) Odd
Gas Type Menu
1) Special
2) Methane
3) Ethane
4) Propane
5) Methane
6) Propylene
7) Butane
8) Spare 6
9) Spare 7
10) Spare 8
Com - 485 Menu
1) Protocol Menu
2) Poll Address
3) Baud Rate Menu
4) Parity Menu
Device Info Menu
1) Universal Rev.
2) Field Device Rev.
3) Software Rev.
4) Write Protect
5) RTC Menu
6) Alignment Status Menu
Sensor Info Menu
1) Active
2) Reference
3) Ratio
4) Gas Gain
5) Absorption
6) Span Factor
7) Sensor Temp
8) Coefficient Menu
History Menu
1) Running Hours
2) Max Temp
3) Min Temp
4) Cal Log
5) Event Log
Analog Code Value Menu
1) Warmup
2) Blocked Optics
3) Calibration
4) General Fault
Status Menu
1) General Info Menu
2) Device Info Menu
3) Sensor Info Menu
4) Fault Status Menu
5) History Menu
*Parameters not used at this time.
**Consult factory before using this function.
NOTE
Refer to “Alarm Relays”
in the Specifications section
of this manual for important
information regarding alarm relays.
