Dakota Ultrasonics

22

Transducer Connectors

Refer to Diagram: The transducer connectors, and battery cover/probe zero disk are
located on the MVX’s top end cap. The transducer connectors are of type Lemo
“00”. Note: There is no polarity associated with connecting the transducer to the
MVX.

Probe Zero Disk & Battery Cover

Refer to Diagram: The Battery cover is the large round disk shown in the diagram.
Note: This same disk is also used as a probe zero disk. Simply remove the cover
when replacing the batteries (3 AA cells). When performing a probe zero function,
simply place the transducer on disk making firm contact. Important: Be sure to
follow the polarity labels located on the back label of the MVX. Note: Rechargeable
batteries can be used, however they must be recharged outside of the unit in a stand
alone battery charger.

RS-232 Connector

Refer to Diagram: The RS-232 connector, located on the bottom end cap, is a 2 pin
female Lemo connector. It is designed to connect directly from the MVX to a
standard AT serial port on a PC. The cable supplied with the MVX is a Lemo to 9 pin
serial cable. Note: This connector is also used to upgrade the MVX with the latest
version of firmware.
