Diagnostics
Provides a multi-page list of system, temperatures, voltages, and
status messages.
•
Configuration
Provides a multi page list (summary) of system setup parameters.
•
Event Log
Displays a list of events, stored in non-volatile memory, with a time-
offset indicating the time since power-up that the event occurred.
Pressing the up and down arrow keys will page up and down through
all events. Pressing the ‘
→’ arrow will display a prompt to erase the
‘Event Log’. Press ‘ →’ arrow again to erase. To cancel the erase
function, press any key other than ‘ENT’.
The following figure lists the potential error codes shown in the log.
The codes can be used by service personnel to help identify a
problem with the transmitter.
Error Code Error Code
"Error Code" "DSP 11"
"DSP 1" "DSP 12"
"DSP 2" "Sensor Over"
"DSP 3" "SER 14"
"DSP Failed" "SER 15”
"DSP 5" "SER 16"
"DSP 6" "SER 17"
"PreAmp Fail" "SER 18"
"DSP 8" "DSP 19"
"DSP 9" "SER 20"
"DSP 10" "SER 21"
Figure 67 Error Codes Listed in Event Log
