Copyright © 2006 CiDRA Corporation Page 9-21
20638-02 Rev 01
Table 14 Transmitter Menu Tree Software Release 03.03.XX (page 6)
Level 1 Level 2 Level 3 Range Description
Sensor
Check
PASS or FAIL.
(Indicate which sensors
failed test)
Performs health check
on each sensor
4-20mA Test
Test 4-20mA outputs
from 4 to 20mA Manual testing of 4-
20mA output #1 and 2
Autoset Gain 1.0, 4.65, 21.55, 98.65
Provides auto
adjustment of pre-
amplifier setting based
on the current process
operating condition
Check/Set
Gain
1.0, 4.65, 21.55, 98.65
Provides for manual
checking and setting of
pre-amplifier gain.
Autoset Gain can
override set point
Gain
Test Gain PASS or FAIL
Test preamp to
determine if gain falls
within range of AGC
parameters
RAM Test PASS or FAIL System memory test
Self Test
DPRAM Test PASS or FAIL Dual port memory test
Keyboard
Test
Red LED illuminates
indicating key is
functional
Test keyboard operation
Diagnostics
Clear History Reset Resets data history
