CiDRA SONARtrac HD VF-100 User Manual

Page 68

Page 9-16

20638-02 Rev 01

Table 14

Transmitter Menu Tree Software Release 03.03.XX

Level 1

Level 2

Level 3

Range

Description

Sensor
Serial #

0000000

Serial number of sensor
band

ID/Wall

ID: 1- 100 in (25.4-
2540mm)

Wall 0 – 100 in (0 to
2540 mm)

Pipe inner diameter and
wall thickness

Size/Sched

2 to 36" size; schedule

Pipe size & schedule

Pipe Size

OD/Wall

ID: 1- 300 in (25.4-
7260mm)

Wall 0 – 100 in (0 to
2540 mm)

Pipe outer diameter and
wall thickness

Liq Spec
Gravity

0 - 999999

Enters the liquid specific
gravity; default water
0.997

Fluid
Properties

Viscosity

0.0000 e-38 to
9.9999 e+38

Enters the liquid
viscosity in Pa-sec

C0 term

0.0000 e-38 to
9.9999 e+38

First term coefficient

C1 term

0.0000 e-38 to
9.9999 e+38

Second term coefficient

Calibration
Coefficients

C2 term

0.0000 e-38 to
9.9999 e+38

Third term coefficient

Flow
Direction

Forward,

Reverse

Sets direction of sensor
head relative to flow

Basic Config

Set
Date/Time

MM/DD/YY
HH:MM:SS

Current date/time;
adjust for daylight
savings as required
