Copyright © 2006 CiDRA Corporation Page 9-10
20638-02 Rev 01
•
Status Messages - ‘S’:
A number of status messages can be displayed in the 20 character
status message field. They are as follows:
Status Message Description
INITIALIZE MODE VF Initialize mode
VF INITIALIZE MODE VF filter holdoff
BELOW MIN VFQUALITY VF quality below configured threshold
SENSOR OVERLOAD DSP indicates sensors are overloaded
DSP FAILURE - n A DSP communication error occurred
Table 10 Status Line Messages
•
Quality Messages ‘Q’:
The Quality Field is a diagnostic field that can be used to view certain
quality values in the transmitter. The factory default is none. If more
than one quality is selected, the transmitter will cycle through each.
The options for display are volumetric flow, pressure and temperature
(if used), band temperature, and a 3-level quality metric. The 3-level
fields represent a Red/Yellow/Green setting for the quality of the
output data. The yellow quality is the bounded value where data can
be considered valid, but is not fully reliable. Red indicates unusable,
and green indicates a good measurement.
Quality Message Description
VQ ‘-1 to +1’ Quality metric of the measurement is between –1 and +1;
+1 is the most robust measurement system can make
RED Quality metric is below the minimum quality factor entered
into the transmitter or the meter is in startup mode
YEL Quality metric is usable but not highly reliable
GRN Quality metric is highly reliable
B Band temperature (°C)
T Process temperature (either from remote sensor or
programmed into system, user selectable °C / °F) (if used)
P Process pressure (either from remote sensor or
programmed into system, user selectable units) (if used)
Table 11 Quality Message Definitions
