Copyright © 2006 CiDRA Corporation Page 9-9
20638-02 Rev 01
9.5.1.2 Operating Transmitter Display
In operating mode the display screen is split into three distinct
portions. The majority of the screen is devoted to a 2-line
measurement display as illustrated below. The bottom portion of the
screen will display status and configuration information.
Figure 54 Operating Transmitter Display
9.5.1.2.1 Line 1 / Line 2
Either line may be configured to display any of the values listed below.
Value Units
Flow Rate Users selectable list of values
Blank Line is blank
Totalizer Users selectable list of values
Table 8 Line 1 and Line 2 Values
9.5.1.2.2 Status Line
The code for information in the status line shown in Figure 52 are
defined as follows:
ID Characters Description Values
S 20 Status Messages See Status Messages Table below
Q 11 Quality Field See Quality Field Message Table below
M 4 Mode See Operating Mode Message Table below
C 1 Communications E – Ethernet or S – Serial
H 1 Hart Activity H – Hart Message received or [blank] – No Activity
W 1 Write Protect W – Write Protected or
[blank] – Not Write Protected
E 1 Event Log Updated ! – Event Log Updated or [blank] – No change to
Event Log since last check
A 1 Activity |/-\ (Cycle changes indicate activity)
Table 9 Status Line Code
V
F
214.5 gal/m
T
O
T
19345 gal
SSSSSSSSSSSSSSSSSSSS QQQQQQQQQQQ MMMM CHWEA
Flow Rate
Total Flow
Line 1
Line 2
Status Line
