Overview
Eppendorf
® PlateReader AF2200
English (EN)
34
View Mode: Select between Matrix and List .
• If Matrix is selected, the data alignment corresponds to a microplate; times per well cannot be
displayed. Not relevant for kinetic result presentation.
• If List is selected, choose between: Align, Rotation, Display Times.
Show : Select between All and Measured .
• If All is selected, the whole plate geometry, including all possible rows and columns, is displayed.
• If Measured is selected, only the results of the measured wells are displayed.
Align : Select between A1A2 or A1B1 .
• If A1A2 is selected, the results are arranged in rows (of the microplate).
• If A1B1 is selected, the results are arranged in columns (of the microplate).
Rotation : Select between Columnwise or Rowwise .
• If Columnwise is selected, the results are displayed in a column (in the Excel sheet).
• If Rowwise is selected, the results are displayed in a row (in the Excel sheet).
Display Times : Select between No time or Time per well .
If No Time is selected, only the values are displayed.
If Time per well is selected, a timespan for each value is displayed.
Data Presentation - Kinetic
Rotation : Select between Columnwise or Rowwise .
If Columnwise is selected, the results are displayed in a column (in the Excel sheet). •
If Rowwise is selected, the results are displayed in a row (in the Excel sheet).
Align : Select between A1A2 and A1B1 .
If A1A2 is selected, the results are arranged in rows (of the microplate).
If A1B1 is selected, the results are arranged in columns (of the microplate).
Display Times : Select between Time per cycle and Time per well.
If Time per cycle is selected, a timespan per cycle is displayed.
If Time per well is selected, a timespan for every well is displayed.
