Eppendorf AF2200 Plate Reader - Manual (Page 14)

Overview
Eppendorf
® PlateReader AF2200
English (EN)
14
4.2 Explorer bar
The Explorer bar is divided into different sections. Each section contains program elements used to create
an individual workflow.
1. Create a workflow either by double-clicking the selected program element or by dragging and dropping
it into the workflow pane.
The following program elements are available:
4.2.1 Labware
Plate
The Plate program element is used to select a plate format from the Plate definition drop-down list.
1. Click Details to see further information on the selected plate.
2. If a plate with cover is used, select the Plate with cover checkbox.
3. The measurement will automatically measure all selected wells of the plate. If you want to measure a
specific well or a range of wells, click the link Pattern in the lower right corner.
Methods Eppendorf prdefined methods
Labware Plate
Pattern
Well
Mode Absorbance
Fluorescence Intensity
Actions Temperature
Shaking
Move Plate
Kinetic Kinetic Cycle
Kinetic Condition
Miscellaneous Comment
User Intervention
Wait for Temperature
Wait Time
Incubation
For accurate measurements it is essential that plate and pattern selected in the software
correspond to the plate and the pattern you use for measuring.
