7
Each output is operated by the logic associated with it in the database.
There are three types of logic for each circuit.
AND All the conditions associated with the circuit must be ON for the circuit to be ON.
OR
Any of the conditions associated with the circuit can be ON for the circuit to be ON.
NOT The associated condition must be OFF or false for the circuit to turn ON.
Logic
SCROLL ESC
MNG: circuit name
SEQUENCE:1 SHED:0
MODE:A or B; STAGE:N
[BACK] [HELP]
Vocation Logic is available when a vocation module is installed. Each output can be tied to
any or all of several interlocks. The output can also be controlled by a NOT interlock, the
circuit will only be operated if the interlock is OFF.
The default condition for vocation logic is true (no connection).
Load Management Logic allows each output circuit to be sequenced on, shed (turned off
below a specific priority or voltage level), tied to either of two operational modes (A or B) and
be staged (controlled by a discrete input). The default condition is true or ON.
Further there are three logic conditions that apply to every output.
Multiplex Logic ties an output to two conditions, these can be AND’ed, OR’ed or Inverted
(NOT). The default condition is false or OFF. The conditions can be inputs or
outputs
SCROLL ESC
MUX: circuit name
1: Condition 1 LOGIC
2: Condition 2
[GO->1] [BACK] [ GO->2 ]
SCROLL ESC
MUX : Pump Panel LTS
1 : Pump LT Switch
[GO->1] [BACK]
SCROLL ESC
MUX: Work Lights
1: Work LT Switch OR
2: Marker LT Switch
[GO->1] [BACK] [ GO->2 ]
All three of the above logic conditions apply to every output and they are ANDed together.
They all must be true for a circuit to operate.
SCROLL ESC
INTERLOCKS: [SCROLL]
CIR:Pump Panel LTS
INTERLOCK : -X-
[BACK] [NEXT]
