Rockwell Automation 1734-AENT POINT I/O EtherNet/IP Adapter Module User Manual
Page 84

Publication 1734-UM011D-EN-P - May 2011
68 Adapter Web Pages
1. From a browser such as Netscape or Microsoft Internet Explorer, enter
the adapter IP address to see the Home page.
2. From the Home page, click Expand to expand options, as in the figure,
or Minimize to see Diagnostics, Configuration, and Browse Chassis
options without the expansion.
ATTENTION
You must use Series C POINT I/O modules with the 1734-AENT
adapter. Series A or B POINT I/O modules will not work with
this adapter.
Enter the adapter IP
address to see the
Home page.
Click Expand to
expand options.
