Publication 1734-UM011D-EN-P - May 2011
106 POINT I/O Module and RSLogix 5000 Software Controller Tag Reference
1734-IT2
2 Channel Thermocouple Input, Isol.
Configuration Data
Data Type Default
Value
Valid Data Values
Cold Junction Notch Filter SINT 1 0=50 Hz
1=60 Hz
Cold Junction Mode SINT 1 0=None
1=Channel 0
2=Channel 1
3=Average Both
Low Engineering Channel 0 INT 0 -32,768…32,767
High Engineering Channel 0 INT 7,000 -32,768…32,767
Alarm Disable Channel 0 SINT 0 0=Alarms Enabled
1=Alarms Disabled
Limit Alarm Latch Channel 0 SINT 0 0=No Latching
1=Alarms Latch
Notch Filter Channel 0 SINT 1 0=50 Hz
1=60 Hz
2=100 Hz
3=120 Hz
4=200 Hz
5=240 Hz
6=300 Hz
7=400 Hz
8=480 Hz
Sensor Type Channel 0 SINT 5 0=mV
1=B
2=C
3=E
4=J
5=K
6=N
7=R
8=S
9=T
Digital Filter Channel 0 INT 0 0…10,000 ms
Low Alarm Limit Channel 0 INT -32,768 -32,768…32,767
High Alarm Limit Channel 0 INT 32,767 -32,768…32,767
Low Low Alarm Limit Channel 0 INT -32,768 -32,768…32,767
High High Alarm Limit Channel 0 INT 32,767 -32,768…32,767
