POINT I/O Module and RSLogix 5000 Software Controller Tag Reference 105
1734-IR2
2 Channel RTD Input
Configuration Data
Data Type Default Value Valid Data Values
Sensor Type Channel 1 SINT 1 0=Ohms
1=100 Ω Pt α 385
2=200 Ω Pt α 385
5=100 Ω JPt α 3916
6=200 Ω JPt α 3916
9=10 Ω Cu α 427
10=120 Ω Ni α 672
11=100 Ω Ni α 618
12=120 Ω Ni α 618
Temperature Mode Channel 1 SINT 1 0=Custom Scale
1=°C
2=°F
3=°K
4=°R
Notch Filter (Channel 0 & 1) SINT 1 0=50 Hz
1=60 Hz
2=100 Hz
3=120 Hz
4=200 Hz
5=240 Hz
6=300 Hz
7=400 Hz
8=480 Hz
Input Data Data Type Default Value Valid Data Values
Data Channel 0 INT 0 -32,768…32,767
Data Channel 1 INT 0 -32,768…32,767
Status Byte Channel 0 SINT 0 Bit 0 Fault
Bit 1 Calibration
Bit 2 LowAlarm
Bit 3 HighAlarm
Bit 4 LowLowAlarm
Bit 5 HighHighAlarm
Bit 6 Underrange
Bit 7 Overrange
Status Byte Channel 1 SINT 0 Bit 0 Fault
Bit 1 Calibration
Bit 2 LowAlarm
Bit 3 HighAlarm
Bit 4 LowLowAlarm
Bit 5 HighHighAlarm
Bit 6 Underrange
Bit 7 Overrange
Output Data Data Type Default Value Valid Data Values
None
