Publication 1734-UM011D-EN-P - May 2011
92 POINT I/O Module and RSLogix 5000 Software Controller Tag Reference
Note that all POINT I/O modules must be series C or above for
RSLogix 5000 software, version 11, compatibility.
The 1734-232ASC/A (series A) is presently the only exception to the series C
requirement. With RSLogix 5000 software, version 11, use it as a generic
1734 module. With RSLogix 5000 software, version 12 or later, it is directly
supported.
Valid Number Ranges for
RSLogix 5000 Data Types
Accepted parameter values are dependent on POINT I/O module type and
tag type.
1734 POINT I/O
Catalog Number
RSLogix5000 Module Description
Specialty I/O
1734-232ASC/C
1 Channel ASCII Interface Module
1734-IJ/C 1 Channel 5V DC Encoder/Counter
1734-IK/C 1 Channel 15…24V DC Encoder/Counter
1734-SSI/C 1 Channel Synchronous Serial Interface
1734-VHSC24/C 1 Channel 15…24V DC Very High-speed Counter
1734-VHSC5/C 1 Channel 5V DC Very High-speed Counter
Type Number Range
BIT 1 Bit 0 or 1
SINT 8 Bit -128…127
INT 16 Bit -32,768…32,767
DINT 32 Bit -2,147,483,648…2,147,483,647
