Rockwell Automation 1734-AENT POINT I/O EtherNet/IP Adapter Module User Manual
Page 10
Publication 1734-UM011D-EN-P - May 2011
x Preface
TCP/IP
The transmission control protocol/internet protocol is a
transport-layer protocol (TCP) and a network-layer protocol (IP)
commonly used for communication within networks and across
internetworks.
Transaction
An exchange of request and data and response and data.
UDP
The user datagram protocol (UDP) is a transport protocol that
provides a very simple but fast capability to send datagrams between
two devices. It is used for I/O (implicit) messaging in EtherNet/IP.
Term
Definition
