To adjust the CRT monitor alignment
W A R N I N G
Do not touch the CRT monitor sweep board. High voltages exist on the sweep board that can
cause personal injury.
Equipment Required
Equipment Critical
Specification
Recommended
Model/Part
Alignment Tool
1
8710-1300
1
1
Turn off the logic analyzer, then disconnect the power cord. Remove the cover.
Refer to chapter 6, "Replacing Assemblies," for instructions to remove the cover.
2
Connect the power cord, insert the operating system disk into the disk drive, then
turn on the logic analyzer.
3
Insert the disk containing the functional performance verification tests (normally
the same disk) into the disk drive, then load the functional performance verification
operating system into the logic analyzer (refer to Chapter 3, To Perform Self Tests).
4–3
