Exploded View
Listing
A1 Main circuit board MP3 Fan guard MP32 Spacer
A2 Keyboard MP4 Rear panel MP33 Label
A3 Switch actuator MP5 Line filter
A4 Probe cable MP6 Handle plate W1 Fan cable
A5 Probe tip MP7 Ground bracket W2 Disk drive cable
A6 Power supply MP8 Cabinet W3 Jumper cable-orange
A7 Disk drive MP9 Cover W4 Jumper cable-white
A8 Monitor assembly MP15 Rear feet W5 Power supply cable
A9 Fan MP18 Mounting plate W6 Front panel cable
MP19 Insulator W7 Monitor sweep cable
H2 Ground spring MP20 Trim strip W8 GPIB cable
H3 Locking pin MP21 Label W9 RS-232C cable
H4 BNC connector MP22 Label
H22 Cable retaining screw MP23 Elastomeric keypad
MP24 RPG knob
MP1 Intensity adjustment MP25 Keyboard panel
MP2 Disk drive bracket MP26 Keyboard spacer
Replacing Assemblies
6–3
