To test the glitch capture
Testing the glitch capture verifies the performance of the following specification:
•
Minimum detectable glitch.
This test checks the minimum detectable glitch on sixteen data channels at a time.
Equipment Required
Equipment Critical Specifications Recommended Model/Part
Pulse Generator 100 MHz 3.5 ns pulse width, < 600 ps rise time Agilent 8131A Option 020
Digitizing Oscilloscope ≥ 6 GHz bandwidth , < 58 ps rise time Agilent 54121T
SMA Coax
(Qty 3) 18 GHz bandwidth Agilent 8120-4948
Adapter (Qty 4) SMA(m)-BNC(f) Agilent 1250-1200
Coupler (Qty 4) BNC (m)(m) Agilent 1250-0216
BNC Test Connector, 6x2 (Qty 4)
Set up the equipment
1 Turn on the equipment required and the logic analyzer. Let them warm up for
30 minutes before beginning the test if you have not already done so.
2 Set up the pulse generator.
Pulse Generator Setup
Channel 1 Channel 2 Period
Delay: 0 ps Delay : 0 ps 22.0 ns
Width: 3.5 ns Width: 3.5 ns
High: −0.9 V High: −0.9 V
Low:
−1.7 V
Low:
−1.7 V
3–17
