To test the CRT monitor signals
Refer to chapter 6, "Replacing Assemblies," for instructions to remove or replace covers and
assemblies.
W A R N I N G
Hazard voltages exist on the power supply, the CRT, and the CRT driver board. This
procedure is to be performed by service-trained personnel aware of the hazards involved,
such as fire and electrical shock.
1
Remove the cover of the instrument.
2
Check the CRT monitor input cable for the signals and the power supplies listed in
the table below. The cable is the wide ribbon cable connecting the monitor to the
acquisition board.
CRT Monitor Cable Signals
Pin
Signal
Pin
Signal
1
NC
2
+12 V
3
Ground
4
Ground
5
+12 V
6
Ground
7
+12 V
8
Ground
9
+12 V
10
HSYNC
11
VSYNC
12
+12 V
13
Ground
14
Ground
15
Ground
16
Video
17
Ground
18
NC
19
Ground
20
NC
Troubleshooting
To test the CRT monitor signals
5–23
