To test the single-clock, multiple-edge, state acquisition
Testing the single-clock, multiple-edge, state acquisition verifies the performance of
the following specifications:
•
Minimum master to master clock time.
•
Maximum state acquisition speed.
•
Setup/Hold time for single-clock, multiple-edge, state acquisition.
This test checks data channels using a multiple-edge single clock at three selected
setup/hold times.
Equipment Required
Equipment Critical Specifications Recommended
Model/Part
Pulse Generator 100 MHz 3.5 ns pulse width, < 600 ps rise time Agilent 8131A option 020
Digitizing Oscilloscope ≥ 6 GHz bandwidth, < 58 ps rise time Agilent 54121T
Adapter SMA(m)-BNC(f) Agilent 1250-1200
SMA Coax Cable (Qty 3) 18 GHz bandwidth Agilent 8120-4948
BNC Cable BNC(m)(m) 48 in. >2 GHz bandwidth Agilent 8120-1840
Coupler BNC(m)(m) Agilent 1250-0216
BNC Test Connector,
6x2 (Qty 4)
Set up the equipment
1 Turn on the equipment required and the logic analyzer. Let them warm up for
30 minutes before beginning the test if you have not already done so.
2 Set up the pulse generator according to the following table.
Pulse Generator Setup
Channel 1 Channel 2 Period
Doub: 0 ps Delay: 0 ps 40 ns
Width: 4.0 ns Dcyc: 50%
High: −0.9 V High: −0.9 V
Low:
−1.7 V
Low:
−1.7 V
COMP: Disabled
(LED off) COMP: Disabled
(LED off)
3–45
