Specifications
The specifications are the performance standards against which the product is tested.
Maximum State Speed 50 MHz
Minimum State Clock Pulse Width
*
3.5 ns
Minimum Master to Master Clock Time
*
20.0 ns
Minimum Glitch Width* 3.5 ns
Threshold Accuracy
± (100 mV + 3% of
threshold setting)
Setup/Hold Time:
*
Single Clock, Single Edge 0.0/3.5 ns through 3.5/0.0 ns,
adjustable in 500-ps increments
Single Clock, Multiple Edges0.0/4.0 ns through 4.0/0.0 ns ,
adjustable in 500-ps increments
Multiple Clocks, Multiple Edges 0.0/4.5 ns through 4.5/0.0 ns,
adjustable in 500-ps increments
* Specified for an input signal VH = -0.9 V, VL = -1.7 V, slew rate = 1 V/ns, and threshold = -1.3 V.
Characteristics
These characteristics are not specifications, but are included as additional information.
Full Channel Half Channel
Maximum State Clock Rate 50 MHz 50 MHz
Maximum Conventional Timing Rate 250 MHz 500 MHz
Maximum Transitional Timing Rate 125 MHz 250 MHz
Maximum Timing with Glitch Rate N/A 125 MHz
Memory Depth 4K 8K
*
Channel Count: 34 17
* For all modes except glitch.
General Information
Specifications
1–3
