To test the single-clock, single-edge, state acquisition
Testing the single-clock, single-edge, state acquisition verifies the performance of the
following specifications:
•
Minimum master to master clock time.
•
Maximum state acquisition speed.
•
Setup/Hold time for single-clock, single-edge, state acquisition.
•
Minimum clock pulse width.
This test checks the data channels using a single-edge clock at three selected
setup/hold times.
Equipment Required
Equipment Critical Specifications Recommended Model/Part
Pulse Generator 100 MHz 3.5 ns pulse width, < 600 ps rise time Agilent 8131A option 020
Digitizing Oscilloscope ≥ 6 GHz bandwidth, < 58 ps rise time Agilent 54121T
Adapter SMA(m)-BNC(f) Agilent 1250-1200
SMA Coax Cable (Qty 3) 18 GHz bandwidth Agilent 8120-4948
BNC Cable BNC(m)(m) 48 in. >2 GHz bandwidth Agilent 8120-1840
Coupler BNC(m)(m) Agilent 1250-0216
BNC Test Connector,
6x2 (Qty 4)
Set up the equipment
1 Turn on the equipment required and the logic analyzer. Let them warm up for
30 minutes before beginning the test if you have not already done so.
2 Set up the pulse generator.
a Set up the pulse generator according to the following table.
Pulse Generator Setup
Channel 1 Channel 2 Period
Delay: 0 ps Doub: 20.0 ns 40 ns
Width: 3.5 ns Width: 3.5 ns
High: -0.9 V High: -0.9 V
Low: -1.7 V Low: -1.7 V
b Disable the pulse generator channel 2 COMP (with the LED off).
3–23
