F74V
● Excelon design allows in-line or modular installation
● Adsorbing type activated carbon element removes
oil vapors and most hydrocarbon odors
● Quick release bayonet bowl
● Long service life of filter element. Minimum life of
400 hours when an oil removal filter is installed
upstream and the filtration temperature is in the
region of 70° to 80°F (20° to 26°C).
● Modular installations with Excelon 72, 73, and 74
series can be made to suit particular applications
Excelon 74 Oil Vapor Removal
Filter 3/8", 1/2", 3/4" Port Sizes
ALE-3-4
Ordering Information. Models listed include PTF threads and a closed bottom metal bowl.
* Maximum flow with 90 psig (6.3 bar) inlet pressure to maintain stated oil vapor removal performance.
Port Size Model Flow* scfm (dm 3 /s) Weight lb (kg)
3/8" F74V-3AN-EMA 27 (13) 2.54 (1.15)
1/2" F74V-4AN-EMA 27 (13) 2.51 (1.14)
3/4" F74V-6AN-EMA 27 (13) 2.46 (1.12)
Alternative Models
F 7 4 - V ★ ★ - ★ ★ ★ ★
Threads Substitute
PTF A
ISO Rc taper B
ISO G parallel G
Options Substitute
No options N
Drain Substitute
Closed bottom (no drain) E
Element Substitute
Adsorbing (Activated carbon A
without color indicator)
Bowl Substitute
Metal M
Transparent with guard
P
Port Size Substitute
3/8" 3
1/2" 4
3/4" 6
ISO Symbols
Auto Drain
