Technical Specifications
55
55
10 Technical Specifications
Table 8 includes the technical specifications:
Table 8: Technical Specifications of the VS-1616A Video Matrix Switcher
INPUT: 16 balanced audio stereo, +4dBu/10k
Ω on detachable terminal blocks
OUTPUTS: 16 balanced audio stereo, +4dBu/50
Ω on detachable terminal blocks
MAX. OUTPUT LEVEL: 20Vpp
BANDWIDTH (-3dB): 100kHz
S/N RATIO: 82.2dB unweighted
CROSSTALK: -80dB @1kHz
CONTROL: Front panel, RS-232, RS-485, contact closure, & IR remote (included)
COUPLING: AC
AUDIO THD + NOISE: 0.04%
AUDIO 2nd HARMONIC: 0.002% @1kHz
POWER SOURCE: 115/230V AC, 50/60Hz, 23VA
DIMENSIONS: 19" x 7" x 2U W, D, H, rack mountable
WEIGHT: 3.5kg (7.8lbs) approx.
ACCESSORIES: Power cord, rack “ears”, Windows®-based Kramer control software,
null-modem adapter
11 Communication Protocol
Table 9 includes the Protocol 2000
1
hexadecimal codes
2
. The
communication parameters are: 9600 baud, with no parity, 8 data bits and
1 stop bit.
1 Full details are available on our Web site: www.kramerelectronics.com
2 This example assumes MACHINE # 1, and node 0
