Viewing the MENU Commands Sequence
39
39
2. Press the TAKE button.
The Displays show the messages:
set FOLLOW SYSTEM?
Press TAKE to execute
current:
breakaway
3. Press the TAKE button again.
The MATRIX Display momentarily shows this message, followed by
the status of the switcher and in the STATUS Display the letter “S” is
displayed behind the blinking cursor:
the UNIT is set in mode
FOLLOW system
4. If the status of the VS-1616A unit differs from that of the other unit(s), set
the VS-1616A unit to the Follow-SYSTEM mode. The MATRIX Display
blinks the new status of the switcher and the TAKE LED blinks. Pressing
the TAKE button
1
To set the VS-1616A unit to function in the Breakaway-from-SYSTEM
mode:
implements all the changes to the same state as the rest
of the system placing the switcher in the Follow-SYSTEM mode.
1. Press the MENU button twice.
The MATRIX Display shows the message:
FOLLOW the system
yes -> TAKE, next -> MENU
2. Press the TAKE button.
The Displays show the messages:
Set BREAKAWAY from system?
Press TAKE to execute
current:
follow SYS
3. Press the TAKE button again.
The MATRIX Display shows the message:
the UNIT is set in mode
BREAKAWAY from system
1 Pressing a different button cancels the operation and the switcher will remain in its previous state
