Operating Your Balanced Stereo Audio Matrix Switcher
29
29
Input # instead of the blinking digits.
The STATUS Display momentarily shows the message:
out # x
from in # y
Where x is the output number and y is the input number
Pressing an OUT-IN combination when your VS-1616A operates in the
CONFIRM mode (and the TAKE LED is lit), requires user confirmation.
To switch one input to one output (CONFIRM mode):
1. Repeat step 1 above.
2. Press the appropriate IN button.
The MATRIX Display shows the 2 blinking digits, representing the input
number and the TAKE LED blinks.
The STATUS Display shows
1
out # x
from in # y
the message:
Where x is the output number and y is the input number
3. Press the TAKE button to confirm the action.
The output switches to the input and the TAKE LED lights.
7.2.2.2 Switching Several Inputs to Several Outputs
In the AT ONCE mode, you need to execute each OUT-IN combination
separately (see section
7.2.2.1 ). When switching many inputs to many
outputs it is recommended to toggle to the CONFIRM mode.
In the CONFIRM mode you can key-in several actions and then confirm
them by pressing the TAKE button once (simultaneously switching
several inputs to several outputs).
To switch several inputs to several outputs in the CONFIRM mode (the
TAKE LED is lit), do the following:
1. Press the appropriate OUT button.
The MATRIX Display shows the 2 blinking digits, representing the
previous input number for that specific output
2
out # x
. If the previous input is
clear, the 2 blinking digits 00 appear in the MATRIX Display.
The STATUS Display shows the message:
1 Continuously, within the limit of the timeout (approximately 30 seconds to one minute)
2 For example, pressing OUT button 9 shows the blinking digits 01 if input 1 was previously routed to OUT 9
