Viewing the MENU Commands Sequence
47
47
STORE/RECALL setting
yes -> TAKE, next -> MENU
2. Press the TAKE button and choose the appropriate Outkey 1 for the AT
ONCE mode (Outkey 2 is for the CONFIRM mode).
The Displays show the messages:
STO/RCL mode
changed
current:
At once
8.7 Choosing What to INDICATE
Choose what is displayed during regular operation: between scrolling the
switcher setup as
Figure 22 illustrates, and showing the IN/OUT range
1
.
Figure 22: Choosing what to INDICATE
To scroll the switcher setup (instead of showing the IN/OUT range), do
the following:
1. Press the MENU button until you reach the what to INDICATE
command.
The MATRIX Display shows the message:
what to INDICATE
yes -> TAKE, next -> MENU
2. Press the TAKE button.
The Displays show the messages:
Use OUTkey to configure
1: scroll SETUP 2: OUTs/INs
Current:
OUTs/INs
1 Useful in an expanded matrix configuration
