Viewing the MENU Commands Sequence
51
51
Figure 23: Machine Identification
8.12 Choosing the Initial RESET
Choose to reset the machine
1
• Current status
to the:
2
• Factory default (resets to the pre-installed factory default state
(reloads the current setup)
3
To reset the machine, do the following:
)
1. Press the MENU button until you reach the initial RESET command.
The MATRIX Display shows the message:
initial RESET
yes -> TAKE, next -> MENU
2. Press the TAKE button.
The MATRIX Display shows the message:
Outkey 1: Current status
2: Factory default
3. Press the OUT button 2, for example, to reset to the factory default.
The TAKE LED blinks and the Displays show the messages:
Reset to factory default
Press TAKE to execute WARNING
!!!!!
4. Press the TAKE button again.
The Displays show the messages:
Reset to factory default
confirm by pressing OUT # 7
WARNING !!!!!
5. Press the OUT # 7.
The machine resets to the factory default and the Displays show the first
messages of the reloading progress (as
Figure 23 illustrates).
1 Without having to switch the power off and on
2 Sometimes called a “soft reset”
3 Each VS-1616A unit ships in its factory default state that is a 16x16 balanced stereo audio matrix, with all setups empty and
each input connected to its corresponding output (for example, 1-to-1)
