KRAMER: SIMPLE CREATIVE TECHNOLOGY

Viewing the MENU Commands Sequence

44

10. Press the TAKE button again.

The MATRIX Display shows the message:

HIGHEST MACHINE ADDRESS

Changed

8.4

Choosing the SWITCHING METHOD Setting

Section

8.4.1

describes the SWITCHING METHOD settings for

standalone units and large matrices. Section

8.4.2

describes how to

configure a SWITCHING METHOD.

8.4.1

Understanding the SWITCHING METHOD Settings

Setting the VS-1616A unit as a Stand-Alone UNIT

1

Setting the VS-1616A unit as one unit in a system of interconnected
switchers (instead of as a Stand-Alone UNIT) provides a choice of 2
SWITCHING METHOD settings:

provides only one

SWITCHING METHOD setting, that is, immediate switching,
irrespective of how the sync is setup on the Menu. Switching occurs
immediately after completion of front panel or dry-contact operation or
immediately after receiving an RS-232 or RS-485 command, or an IR
command. The switching is independent of the video vertical reference.

NoVIS, (as described above)
MTX (SYNC from Matrix) - the vertical interval of the video

reference (selected on any video in a system of interconnected
switchers) is present on the “SYNC” RS-485 terminal block
connector

2

To choose the MTX (SYNC from Matrix) setting

. This reference signal applies to all switchers in the

multi-switcher system and facilitates switching all units
simultaneously

3

Figure 21

as the example in

illustrates:

• Connect the RS-485 terminal block connectors

4

• Connect and set the video reference signal on the VS-162V unit

to EXT (external sync) or INT# 1 (internal sync)

between both

switchers in the multi-switcher system

• Set the video reference on the VS-1616A unit to the MTX

1 Via the MACHINE ADDRESS setting (as section

6.6.1

describes)

2 Item 5 in

Figure 1

3 This sets the matrix sync configuration from another (Master) machine

4 Via a straight connection of all four pins
