Installing the Balanced Stereo Audio Matrix Switcher
11
11
1. Set the same MACHINE #
1
6.6.1 (see section ) on both VS-1616A units.
2. Set the MACHINE ADDRESS # on one VS-1616A unit to 1 and on the
other VS-1616A unit to 7 (refer to Figure 7).
3. Set DIP 6 OFF on both VS-1616A units.
4. Interconnect each corresponding EXTENSION / UNBALANCED OUT
connector between both VS-1616A units (1 to 1, 2 to 2, 3 to 3, up to and
including 16 to 16).
5. Connect the balanced outputs 1 to 16 from the first VS-1616A unit
(MACHINE ADDRESS # 7)
2
.
Alternatively, you could connect the balanced outputs from the second
VS-1616A unit (MACHINE ADDRESS # 1)
3
6. The inputs on the MACHINE ADDRESS # 1 are system inputs 1 to 16,
and the inputs on the MACHINE ADDRESS # 7 are system inputs 17 to
32. The 2 VS-1616A units form a 32x16 switcher.
, or if required, you could
connect the balanced outputs from both the first and second VS-1616A
units, forming a 1:2 distribution amplifier.
1 For a single group, this is usually set to # 1, as in the example in Figure 9
2 To the audio acceptors (not shown in Figure 9 )
3 However, connecting the balanced outputs from one unit suffices
