KRAMER: SIMPLE CREATIVE TECHNOLOGY
Operating Your Balanced Stereo Audio Matrix Switcher
32
Where x is the output number
3. Press the TAKE button to confirm the action.
The input is cleared and the TAKE LED lights. The MATRIX Display
does not show any Input # in its place.
7.2.3.2 Clearing Several Outputs
To clear several outputs (in the AT ONCE mode):
1. Press the appropriate OUT button.
The MATRIX Display shows the 2 blinking digits, representing the
present input number for that specific output
1
out # x
. If the present output is
clear, the 2 blinking digits 00 appear in the MATRIX Display.
The STATUS Display shows the message:
where x is the output number.
2. Press the OFF button.
The output is cleared and the MATRIX Display does not show any Input
# in its place.
The STATUS Display momentarily shows the message:
out # x
reset
where x is the output number.
To clear several outputs (in the CONFIRM mode (the TAKE LED is lit)):
1. Repeat step 1 above.
2. Press the OFF button.
The MATRIX Display shows the 2 blinking digits 00 instead of the
previous 2 blinking digits and the TAKE LED blinks.
The STATUS Display shows
1
the message:
out # x
reset
where x is the output number.
3. Press the second appropriate OUT button, by repeating step 1 above.
4. Repeat step 2 above.
5. Continue with this OUT-OFF button sequence, pressing the appropriate
OUT buttons and the OFF, as required.
1 For example, pressing OUT button 9 shows the blinking digits 01 if input 1 was previously routed to OUT 9
