Operating Your Balanced Stereo Audio Matrix Switcher
33
33
The MATRIX Display shows the sets of 2 blinking digits, representing
the present input number for each specific output.
6. After completing the sequence, press the TAKE button to confirm the
actions.
The inputs are cleared and the TAKE LED lights. The MATRIX Display
does not show any Input # in its place.
7.2.3.3 Clearing All Outputs
To clear all outputs (in the AT ONCE mode):
1. Press the ALL button.
The MATRIX Display shows all the sets of 2 blinking digits (each
representing the present input number connected to that respective output)
blinking simultaneously.
The STATUS Display shows the message:
all OUTs
2. Press the OFF button
1
Reset ALL connections
!!!!
.
All the outputs are cleared and the MATRIX Display momentarily shows
the message:
To switch one input to all the outputs (in the CONFIRM mode (the
TAKE LED is lit)):
1. Repeat step 1 above.
2. Press the OFF button
1
.
The TAKE LED blinks and the MATRIX Display shows the message:
Reset ALL ?
Press TAKE to execute
3. Press the TAKE button to confirm.
All the outputs are cleared and the TAKE LED lights.
7.2.4 Storing and Recalling Setups
You can store up to 99 settings in the non-volatile memory with the
ability to recall each of those settings.
1 You can press the OFF button first, and then the ALL button (the order is irrelevant)
