Table of Hex Codes for Serial Communication (Protocol 2000)
42
lists the Hex values that set the audio input gain:
Table 14: VP-16x18AK Hex Codes for Setting the Audio Input Gain
IN 1
…
IN 5
…
IN X
Level
[Rel]
16 81 80
*
81
…
16 85 80
*
81
…
16 8X 80
*
81
Mute
…
…
…
16 81 87
*
81
…
16 85 87
*
81
…
16 8X 87
*
81
-100dB
Mute
…
…
…
16 81 B9
*
81
…
16 85 B9
*
81
…
16 8X B9
*
81
-50dB
…
…
…
16 81 EB
*
81
… 16 85 EB
*
81
…
16 8X EB
*
81
0dB
…
…
…
16 81 FF
*
81
…
16 85 FF
*
81
…
16 8X FF
*
81
+20dB
(Max)
* BYTE 3 = 0x80 + Gain Value (0x00-0x7F)
lists the Hex codes that increase or decrease the audio output gain:
Table 15: VP-16x18AK Hex Codes for Increasing/Decreasing the Output Gain
OUT 1
…
OUT 5
…
OUT Y
Increase
18 81 80 81
…
18 85 80 81
…
18 8Y 80 81
Decrease
18 81 81 81
…
18 85 81 81
…
18 8Y 81 81
lists the Hex codes that set the audio output gain.
Before sending the any of the codes in
, the command 2A 87 80 81
must be sent.
Table 16: VP-16x18AK Hex Codes for Setting the Audio Output Gain
OUT 1
…
OUT 5
…
OUT Y
Level
[Rel]
16 81 80
*
81 … 16 85 80
*
81 …
16 8Y 80
*
81
Mute
…
…
…
16 81 94
*
81 … 16 85 94
*
81 …
16 8Y 94
*
81 -100dB Mute
…
…
…
16 81 C6
*
81
…
16 85 C6
*
81
…
16 8Y C6
*
81
-50dB
…
…
…
16 81 F8
*
81 … 16 85 F8
*
81 …
16 8Y F8
*
81
0dB
…
…
…
16 81 FF
*
81 … 16 85 FF
*
81 …
16 8Y FF
*
81 +10dB (Max)
*BYTE 3 = 0x80 + Gain Value (0x00-0x7F)
