Table of Hex Codes for Serial Communication (Protocol 2000)
41 41
Table 10: VP-16x18AK Audio Output Gain Codes
OUTPUT 1 … OUTPUT 5 … OUTPUT Y*
Level
[Rel]
#AUD-LVL 2,1, -100CR … #AUD-LVL 2,5, -100CR … #AUD-LVL 2,Y, -100CR -100dB Mute
…
…
…
#AUD-LVL 2,1, -50CR … #AUD-LVL 2,5, -50CR … #AUD-LVL 2,Y, -50CR -50dB
…
…
…
#AUD-LVL 2,1, 0CR … #AUD-LVL 2,5, 0CR … #AUD-LVL 2,Y, 0CR 0dB
…
…
…
#AUD-LVL 2,1, 10CR
… #AUD-LVL 2,5, 10CR … #AUD-LVL 2,Y, 10CR +10dB (Max)
* Where X is the output number from 1 - 8. For example, for channel 7 and relative level -50dB, #AUD-LVL 2,7, -50CR
15 Table of Hex Codes for Serial Communication (Protocol
2000)
The Hex codes listed in this section are used to set video channels for a
single machine (set as machine number 1) connected via either RS-232 or
Ethernet. Similar hex codes are used when the VP-16x18AK is connected
via RS-485 and the VP-16x18AK is set to machine number 2.
Table 11 lists the Hex codes that switch video channels:
Table 11: VP-16x18AK Hex Codes for Switching Video Channels via RS-232/RS-485
Switching Video Channels
OUT 1 … OUT 5 … OUT Y
IN 1 01 81 81 81
… 01 81 85 81 … 01 81 8Y 81
…
…
…
…
IN 5 01 85 81 81
… 01 85 85 81 … 01 85 8Y 81 …
…
…
…
IN X 01 8X 81 81
… 01 8X 85 81 … 01 8X 8Y 81
Table 12 lists the Hex codes that switch video channels:
Table 12: VP-16x18AK Hex Codes for Switching Audio Channels via RS-232/RS-485
Switching Audio Channels
OUT 1 … OUT 5 … OUT Y
IN 1 02 81 81 81
… 02 81 85 81 … 02 81 8Y 81
…
…
…
…
IN 5 02 85 81 81
… 02 85 85 81 … 02 85 8Y 81
…
…
…
…
IN X 02 8X 81 81
… 02 8X 85 81 … 02 8X 8Y 81
Table 13 lists the Hex codes that increase or decrease the audio input gain:
Table 13: VP-16x18AK Hex Codes for Increasing/Decreasing the Audio Input Gain
IN 1 … IN 5 … IN X
Increase
18 81 86 81 … 18 85 86 81 … 18 8X 86 81
Decrease 18 81 87 81
… 18 85 87 81 … 18 8X 87 81
