Operating the VP-16x18AK Remotely Using a Web Browser
34
2. Click Recall.
A confirmation message appears.
3. Click OK.
The configuration from Preset 03 is loaded.
Note: You can also recall a preset in the Offline mode (see Figure 24 ) and
make it active when you press the Take button (see Section 9.2.3 ).
Figure 23: Recalling a Preset in Offline Mode
9.2.5 Locking the Front Panel Buttons
You can lock the front panel buttons to prevent tampering.
To lock the front panel buttons:
• Click the padlock icon
Note: Locking the front panel buttons does not disable remote operation of
the unit via Ethernet, RS-232 or RS-485.
9.3 Audio Input Gain Control Page
The Audio Gain page lets you set the gain for each of the input channels
independently.
Figure 24: Audio Gain Control Page
