Table of ASCII Codes for Serial Communication (Protocol 3000)
40
14
Table of ASCII Codes for Serial Communication
(Protocol 3000)
list the ASCII values to switch an input to an output for
a single VP-16x18AK machine. For more detailed information, see
Protocol 3000 (
Table 7: VP-16x18AK Video Signal Codes for Protocol 3000
OUT 1
…
OUT 5
…
OUT Y
IN 1
#V 1>1 CR
…
#V 1>5 CR
…
#V 1>Y CR
…
…
…
IN 5
#V 5>1 CR
…
#V 5>5 CR
…
#V 5>Y CR
…
…
…
IN X
#V X>1 CR
…
#V X>5 CR
…
#V X>Y CR
Table 8: VP-16x18AK Audio Signal Codes for Protocol 3000
OUT 1
…
OUT 5
…
OUT Y
IN 1
#A 1>1 CR
…
#A 1>5 CR
…
#A 1>Y CR
…
…
…
IN 3
#A 5>1 CR
…
#A 5>5 CR
…
#A 5>Y CR
…
…
…
IN X
#A X>1 CR
…
#A X>5 CR
…
#A X>Y CR
lists the codes that set the audio input gain. For more detailed
Table 9: VP-16x18AK Audio Input Gain Codes
INPUT 1
…
INPUT 5
…
INPUT X*
Level
[Rel]
#AUD-LVL 1,1, -100CR
…
#AUD-LVL 1,5, -100CR
…
#AUD-LVL 1,X, -100CR
-100dB Mute
…
…
…
#AUD-LVL 1,1, -50CR
…
#AUD-LVL 1,5, -50CR
…
#AUD-LVL 1,X, -50CR
-50dB
…
…
…
#AUD-LVL 1,1, 0CR
…
#AUD-LVL 1,5, 0CR
…
#AUD-LVL 1,X, 0CR
0dB
…
…
…
#AUD-LVL 1,1, 20CR
…
#AUD-LVL 1,5, 20CR
…
#AUD-LVL 1,X, 20CR
+20dB (Max)
* Where X is the input number from 1 - 8. For example, for channel 7 and relative level -50dB, #AUD-LVL 1,7, -50CR
lists the codes that set the audio output gain. For more detailed
