YSRWJ-...-A

Festo YSRWJ-...-A 0008NH English

13

Positioning element type YSRWJ-...

English

1

Operating parts and connections

1

2

3

7

5

6

4

1

Thread for fastening and positioning the positioning element

2

Lock nut

3

Capstan nut for setting the end position

4

Shock absorber for end position cushioning secured with lock nut

5

Groove for proximity switch

6

Positioning plunger

7

Rubber buffer (only with YSRWJ-7/8-...)

Fig. 1
