Installation
61 GB
5
Attach the other end of the wire rope to the material
near to where the camera is to be installed.
Use an M5 (3/16 inch) hexagon socket head cap
screw (not supplied). Attach the wire rope to the
material independent of the surface where the
ceiling bracket (B) is attached.
6
Insert the protrusions on the ceiling bracket (A) into
the spaces prepared in the ceiling bracket (B) with
the a hole in the front of the ceiling bracket (A)
aligned with the hole on the ceiling bracket (B),
then temporarily attach them by turning the ceiling
bracket (A) with the camera counterclockwise.
M5 (3/16 inch) hexagon socket
head cap screw
Wire rope
(supplied)
Ceiling bracket
(B)
Ceiling
bracket (A)
Align.
a hole
hole
