VIDEO OUT Menu
41 GB
VIDEO OUT Menu
HD-RGB/COMPONENT
FORMAT
Select the signal output from the RGB/
COMPONENT connector on the camera.
YPbPr: Outputs analog component signals.
RGB: Outputs RGB signals.
ADD SYNC
Appears when RGB is selected with FORMAT and
specifies whether to add a sync signal.
RGB: Outputs each R, G and B signal with a sync signal
added.
OFF: Outputs each R, G and B signal with no sync
signal added.
SYNC TYPE
Appears when either RGB or YPbPr is selected with
FORMAT and specifies the type of a sync signal.
SYNC: Outputs the tri-level sync.
VD: Outputs the bi-level sync.
SD-VIDEO/S VIDEO
IMG SIZE
Select the aspect ratio of the signal output from the
VIDEO or S VIDEO connector on the camera.
16:9[LETTER]: The image is displayed in 16:9
letterbox.
4:3[CROP]: The image is displayed in 4:3 edge crop.
4:3[SQUEEZE]: The image is displayed in 4:3
squeeze.
Note
If the SDI output on the camera is set to SD, IMG SIZE
of the SD-SDI output is also changed when IMG SIZE
is changed.
SETUP
Select whether 7.5IRE setup is added to the signal
output from the
VIDEO or S VIDEO
connector on the camera.
ON: Outputs signals with 7.5IRE setup added.
OFF: Outputs signals with no 7.5IRE setup added.
Notes
• The SETUP item does not appear when an HD signal
of 1080/50i or 720/50p format is output.
• 7.5IRE setup is not added to output signals from the
SD-SD1 output.
HD-RGB/COMPONENT
>FORMAT YPbPr
SYNC TYPE SYNC
SD-VIDEO/S VIDEO
IMG SIZE 16:9[LETTER]
SETUP OFF
