PDU Display Interface: Alarms Screen

150kW InfraStruXure PDU—Operation and Configuration

23

Alarm Setup

Use this option of the Alarms screen to access the following options:

Alarm Beeper

Use this option of the Alarms screen to turn the alarm beeper ON or OFF.

Loading Limits

Configure the following in amps and as a percentage of full load:

Out High: The upper limit for output current
Out Low: The lower limit for output current
Out Neut: The upper limit for current on the neutral wire for

the output phases

Voltage Limits

Configure the following as a percentage under or over the rated
voltage:

Input: The allowed range for input voltage
Output: The allowed range for output voltage

Other Limits

Configure these limits:

Frequency: The frequency variation, in hertz, that is acceptable

for the output current.

Gnd Current: The ground current, in amps, that is acceptable.

Global Alarm
Config

Set all the loading limits or all the voltage limits simultaneously as a
percentage of full load:

Load Limits: Set the same percentage for the upper limit for

output current, the lower limit for output current, and the upper
limit for current on the neutral wire for the output phases. (Use
the Loading Limits option to set these thresholds individually).

Volt Limits: Set the same percentage for the high and low

thresholds for input and output voltage. (Use the Voltage
Limits
option to set these thresholds individually.)

Select Apply Now and then YES to implement your changes.

Note

If an alarm limit has been disabled, “OFF” is displayed.
