8
Collegamenti dell’Home Theater
Collegamento di televisore e apparecchiatura DVD (continua)
Cavo di collegamento
Collegamenti audio analogici
Vi sono alcune limitazioni all’uscita digitale dell’apparecchiatura DVD, pertanto potrebbe essere necessario effettuare questo
collegamento. Per i collegamenti video,
➡
pagine 6 e 7.
Pannello posteriore
Lettore DVD Registratore
DVD (R) (L)
AUDIO
OUT
(R) (L)
AUDIO
OUT
Collegamento separato a 6 canali (per suono DVD-Audio di alta qualità)
Pannello posteriore
Apparecchiatura DVD
SUBWOOFER CENTER (R) (L)
FRONT
(R) (L)
SURROUND
Vedere anche “Riproduzione di
DVD-Audio”, ➡ pagina 20.
Bianco (L)
Rosso (R)
Controllare la forma e inserire
il cavo in modo corretto nel
terminale.
Collegamento del cavo digitale a fibra ottica
Collegamenti dell’Home Theater
Non piegare il
cavo!
