- 12 -
Charging and recording time
∫ Charging/Recording time
≥ Temperature: 25 oC (77 oF)/humidity: 60%RH
≥ “h” is an abbreviation for hour, “min” for minute and “s” for second.
≥ These times are approximations.
≥ The indicated charging time is for when the battery has been discharged completely.
Charging time and recordable time vary depending on the usage conditions such as high/
low temperature.
≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping
recording, turning this unit on/off, etc.
≥ The power lamp flashes (Flashing with approx. 1 second period (off for approx. 0.5 second, on for
approx. 0.5 second)) when the remaining battery time becomes low.
≥ The main unit heats up after use or charging. This is not a malfunction.
≥ For information about charging with a mobile USB charger or an AC adaptor, check the support
site.
http://panasonic.jp/support/global/cs/e_cam/index.html
(This site is English only.)
Charging time Pixels/Frame rate
Maximum continuous
recordable time
Actual recordable
time
4 h 30 min
[3840 k2160/30p] 1 h 20 min 40 min
[1920 k1080/60p] 1 h 50 min 55 min
[1920 k1080/30p] 2 h 10 min 1 h 5 min
[1280 k720/60p] 1 h 45 min 55 min
[1280 k720/30p] 2 h 5 min
1 h 5 min [848 k480/30p] 2 h 10 min
[1920 k1080/60fps] 2 h 5 min
[1280 k720/120fps] 2 h
1 h
[848 k480/240fps] 1 h 55 min
The power plug is the disconnecting device. Install this unit so that the power plug can be
unplugged from the socket outlet immediately.
Battery capacity indication
≥ The display changes as the battery capacity reduces. # # # #
If the battery discharges, then will flash red.
