Names and functions of main parts – Panasonic HX-A500H User Manual
Page 10
- 10 -
1
LCD monitor
2
Power lamp (
)
3
Power button [
] (
)
4
Wi-Fi Transmitter
5
Access lamp (
)
6
Joystick
Use the joystick to operate the menu screen or
to use a Wi-Fi mode. Move the joystick up,
down, left or right, and then press the joystick to
set an item.
)
j Displaying the information screen (
)
j Checking the motion picture/still picture
you have recorded (Rec Review) (
)
)
7
Recording start/stop button (
8
NFC touch area [
] (
9
Speaker
10
Camera (
)
11
Lens (
)
12
Mic
13
Camera/main unit connection cable
≥ This cable is not removable.
14
USB terminal [
] (
15
Reset button [RESET]
≥ If this unit fails to operate correctly, such as
when this unit cannot be turned on/off, press
the reset button by using a paper clip or a
similar object.
16
Card slot (
)
17
LOCK switch (
)
18
Side cover (
)
Names and Functions of Main Parts
6
4
1
3
2
5
7
10
12
13
9
11
18
17
14
15
16
8
Main unit
Camera
unit
